Verifying safety, before it's tested by accident

Ground Bond Testers

Verify the integrity of protective earth (ground) connections on electrical equipment, helping prevent shock hazards from chassis faults.

Impulse Winding Testers

Evaluate the insulation integrity and winding quality of coils, transformers, motors and inductors to catch turn-to-turn faults.

Multifunction Safety Compliance Analyzers

Integrated hipot, insulation, ground bond and leakage current testing in one analyzer, helping manufacturers verify compliance with IEC and UL standards.

Automatic Transformer Test Systems

High-speed automated testing of transformers, chokes and magnetic components for production, incoming inspection and R&D labs.

Thermal Imaging Cameras

Non-contact infrared cameras for detecting overheating connections, unbalance and overload before they cause breakdowns or fires.

Insulation Resistance Meters

Apply a high DC test voltage to detect insulation deterioration and leakage current in cables, motors, transformers and switchgear.

Product Specifications

Featured Instruments

Multifunction Safety Compliance Analyzer

Product Overview

A Multifunction Safety Compliance Analyzer is an integrated electrical safety test system designed to perform multiple safety compliance tests using a single instrument. It combines AC Withstand Voltage, DC Withstand Voltage, Insulation Resistance, Ground Bond, Continuity, Leakage Current, and Electrical Performance Testing, making it ideal for production lines, R&D laboratories, quality control, and compliance testing of electrical and electronic products.

These analyzers help manufacturers verify compliance with IEC, UL, CSA, EN, and other international electrical safety standards while reducing test time through programmable automatic test sequences.

7-in-1 Test Functions

AC Withstand Voltage Test (Hipot)
DC Withstand Voltage Test
Insulation Resistance Test
Ground Bond Test
Continuity Test
Leakage Current Test
Electrical Performance Test

Key Features

Automatic Test Sequencing
PASS / FAIL Comparator
ARC Detection
Open / Short Circuit Detection (OSC)
Hardware Contact Check (CK)
Breakdown Voltage Detection
Large Color Touchscreen
Internal Memory
USB Data Storage
LAN, USB & RS-232 Communication
PLC / Handler Interface
SCPI Remote Programming
Multi-Channel Versions Available

Technical Specifications

Parameter	Minimum Range	Maximum Range	Unit
AC Hipot Voltage	50 V AC	5 kV AC	V
AC Leakage Current	1 µA	100 mA	A
AC Output Power	200 VA	500 VA	VA
DC Hipot Voltage	50 V DC	6 kV DC	V
DC Leakage Current	0.1 µA	25 mA	A
DC Output Power	120 VA	150 VA	VA
Insulation Resistance	0.05 MΩ	50 GΩ	Ω
Insulation Test Voltage	50 V	6000 V	V
Ground Bond Current	3 A	40 A AC	A
Ground Resistance	0.1 mΩ	600 mΩ	Ω
Continuity Test Current	100 µA	100 mA	A
Continuity Resistance	0 Ω	10 kΩ	Ω
Leakage Current Test	0 µA	10 mA	A
Electrical Performance Voltage	0 V	277 VAC	V
Electrical Performance Current	0 A	16 A	A
Power Measurement	0 W	4500 W	W
Power Factor	0.000	1.000	PF
Test Timer	0.3 s	999 s	Seconds
Memory	100 Files	50 Steps/File	—
Display	7-inch TFT Capacitive Touchscreen, 800 × 480 Pixels		—

Typical Applications

Household Appliances
Power Supplies
Electric Motors

Ground Bond Tester

High-current AC/DC ground bond testing with contact check, open-circuit detection and PLC/handler interfacing for automated production line integration.
